SEPPES hard high-speed door, also known as aluminum alloy high-speed door, is a new type of metal fast door with anti-theft and high-speed partition. It is an innovative product in the field of industrial technology. SEPPES hard high-speed doors are not only resistant to strong wind, but also have a high degree of sealing, reliability and practicality. The technology of rigid fast doors is at the leading level in the field of industrial doors. The transparent door slats are made of polypropylene glass, and gray transparent slats can also be installed. Therefore, it is suitable for chemical, pharmaceutical, automotive industry (painting workshop) and food processing and other fields. The rigid high-speed door can protect its good sealing performance even under high pressure, and can withstand strong winds of more than 11 levels. The opening speed of the door varies with its size, the fastest can reach 2-3m/s.
Motor system: SEPPES brand motor, geared motor, low noise, high efficiency, long life, safety factor is above 1.3
Control system: adopts microcomputer frequency conversion speed regulation, the door body runs more smoothly
Lifting mechanism: aluminum alloy oriented load-bearing track, so that there is no friction between the curtain and the track, ensuring low-noise and high-speed operation
Door curtain mechanism: a restrained door curtain mechanism, which is composed of aluminum alloy curtain sheets, flexible connection rubber strips, load-bearing rubber chains, guide wheels and other parts. Transparent windows are optional. The flexible connection part has a folding life of more than one million times; The guide wheel made of urethane slides in the aluminum alloy track, running at high speed without friction and noise
Safety system: infrared safety protection of electric eyes on both sides and bottom safety protection
Wind resistance: 30 M/S (DIN EN 12424 wind resistance level 11)
Thermal insulation performance: thermal insulation coefficient: K-VALUE 0.4W/M2K
Operating speed: 1-2.5m/s
Overall appearance: laser-cut, precisely formed galvanized sheet doorpost, motor cover, beautiful appearance, no rust, dustproof and easy to clean
Mechanism improvement: worm wheel type turntable is used to make the door body suck in quickly and absorb vibration and noise
Control box: thickened IP54 control box, in line with national electrical safety standards
Insulation protection: Ip54 is waterproof and dustproof even when used in harsh environments
Switch mode: standard one-button button with emergency stop switch, alternative: radar induction / geomagnetic ring induction / pull rope switch
