Dustproof fast shutter door features:
1. Basic function: The fast shutter door is designed according to the requirements of frequent entry and exit of vehicles on the factory floor. The fast door can protect the cleanliness of the interior of the workshop, prevent the internal and external air circulation, and the transmission of temperature.Various opening methods are more in line with customer needs.
2. Special protection: The fast rolling shutter door can be equipped with optional airbag protection at the bottom of the door to protect people from entering and exiting. The sudden drop of the curtain will not hurt people and will automatically run in reverse. The basic setting is the infrared anti-lighting eye protection at the bottom of the door, which can effectively sense the object in the middle of the door and protect the curtain from falling.
3. Intelligent design: The humanized design is reflected in the control system. There will be an LCD screen on the control subject, which can play information like a TV and show the basic operating information of the quick door. When a fault occurs, a digital code will be prompted. , Can be trimmed and adjusted in time.
Basic parameters of dustproof fast shutter door
1. Opening speed:0.6-1.5m/s(adjustable) 2.0-2.5m/s(Advanced motor)
2. Doorway range:Width 1250-5000mm, height within 5 meters.Beyond this range, you need to customize other models and strengthen wind resistance.
3. Applicable temperature:—40℃~80℃
4. voltage range:220V/380V(Asia),If other voltages can be customized.
Dustproof fast shutter door control method:
1. Switch button: This method is to control the normal operation of the fast shutter door through two- or three-button buttons. The operation is simple and suitable for situations where there are not many people entering and exiting.This is also the basic configuration and can be used in conjunction with other sensing methods.
2. Pull switch: In the case that such a rope needs a certain space on the outside, when installing the rope, a long protruding rod is first installed outside the door, and a rope is tied below the rod to pull in and out. The rope can be used; this type of rope is far away from the door, and all the less vehicles can pull in the rope at a long distance.
3. Remote control: The remote control is within a certain range. Generally, the remote control is within 20-30 meters. If it exceeds this range, it will be unnecessary.
4. Radar geomagnetism: Radar induction and geomagnetic induction are both self-inductive, but the range of induction is not the same as the object; the radar is automatically turned on by sensing the objects moving around, and there is a certain range of distance; the geomagnetic is through the embedded coil Way, you can choose the required sensing distance, which can be far or near.
5. Card access: This opening is to restrict the access of personnel. Only those who know the password and have a card can enter.
